MP102 QUICK SETUP
1. Make sure all items listed on the front of this guide
are included in the box.
2. READ SAFETY INSTRUCTION BOOKLET BEFORE
USING THE PRODUCT.
3. Study this setup diagram.
4. Place MP102 in an appropriate position for
operation.
5. Make sure all devices are turned off and all faders
and gain knobs are set to “zero”
6. Connect all stereo input sources as indicated in the
diagram.
7. Connect the stereo outputs to power amplifier(s),
tape decks, and/or other audio sources.
8. Plug all devices into power.
9. Switch everything on in the following order:
x audio input sources (i.e. turntables or CD
players)
x MP102
x last, any amplifiers or output devices
10. When turning off, always reverse this operation by,
x turning off amplifiers
x MP102
x last, any input devices
11. Go to http://www.numark.com
for product
registration.
More information about this product may be found at
http://www.numark.com
REAR CONNECTIONS
1. XLR Balanced Audio Connectors – Low
impedance XLR output connectors.
2. Power Plug Connector - Plug your supplied power
cord in here.
3. Voltage Selector - Set this switch to the voltage
for your location.
4. RCA Audio Connectors - Connect your CD player
to your mixer from this line level output.
5. Digital Output - The format is type 2, form 1, also
known as S/PDIF (Sony/Phillips Digital Interface
Format). In order to use the digital output you
should not use variable pitch slider and the pitch
bend buttons. If you adjust the pitch, other devices
may not read the digital output properly because
the sampling rate changes
