Numatic NVQ 240-21 - Page 9

Schematic Diagram
1 2 3 4 5 6
NVQ 240-21
NVQ 370-21
NVQ 380-21
NVQ 470-21
NQS 250-21
NQS 250B-21
NQS 350-21
NQS 350B-21
9 L
15 L
15 L
27 L
9 L
9 L
14 L
14 L
26.4
m
9.65 kg
10 kg
12 kg
12 kg
10 kg
10 kg
13.6 kg
14 kg
75 dB
(A)
0.5 dB
Class I
Class
II
360 mm x 370 mm x 415 mm
355 mm x 355 mm x 485 mm
355 mm x 355 mm x 485 mm
360 mm x 450 mm x 655 mm
340 mm x 340 mm x 395 mm
340 mm x 340 mm x 395 mm
395 mm x 350 mm x 560 mm
395 mm x 350 mm x 560 mm
1 2 3 4 5 6
Drum Size
Cleaning
Range
Weight
(Ready to
work)
Sound Pressure (LpA)
Uncertainty (KpA)
Protection
Class
Dimensions
Data
For best performance make sure you use genuine Numatic bags
604015
240 / 250 Drum HepaFlo Dust
Bags (Pack of 10) NVM-1CH
604016
370 / 380 Drum HepaFlo Dust
Bags (Pack of 10) NVM-2BH
604018
470 Drum HepaFlo Dust Bags
(Pack of 10) NVM-3AH
HepaFlo Dust Bags
