Nuna pipa lite rx User Manual

50 PIPA lite rx instructions 51PIPA lite rx instructions
Recline Adjustment
(continued)
Check the Installation
After recline adjustment, check
that the child restraint is still
securely attached to the base by
pulling up on the handle.
Releasing Child Restraint
from PIPA RELX
™
Base
1
- To release the child restraint,
squeeze the child restraint
release button (1) located on
the base, then pull the child
restraint up (2).
Uninstalling PIPA RELX
™
Base
When Installed with Rigid Latch:
2 - Squeeze the rigid latch release
buttons.
3 - Pull the base off of the bars.
4 - Rotate the rigid latch back into
neutral storage position.
When Installed with Lap and
Lap/Shoulder Belt:
5 - Lift the lock off release button.
6 - Unbuckle the vehicle belt and un-
route the shoulder and lap belt
from the base. Remove the base.
2
1
1
2
3
4
5
6

Nuna pipa lite rx Specifications

General

Brand	Nuna
Model	pipa lite rx
Category	Baby Carrier
Language	English
