correctly.
Take note of the position of the inner flange, if this should fall
off it must be replace as shown in (Pic.15.). Remove any wood
debris from around the motor spindle and the two flanges.
Fit the new blade as shown in (Pic.16) ensuring that the direction
of rotation arrow on the blade corresponds with the direction of
rotation arrow on the fixed guard. Replace the retaining flange
and blade bolt.
Tighten the hex socket screw securely but do not over tighten.
NOTE: Check the tightness of the hex socket screw before,
during and after each use.
Take up the tension on blade guard and remove the piece
of wood or screwdriver that is holding it in the open position.
Slowly release the guard so that it covers the blade.
Check the operation of the blade guard making sure that it
operates correctly. The operation is complete and your machine
is ready for use.
TECHNICAL SPECIFICATION
Voltage 230 - 240V~50 Hz
Motor 1200 W
No load speed 5000 min
-1
Max Cut 90° 55mm
Blade Size 185mm x (Bore) 20 mm
Sound Pressure Level L
PA
95,6 dB(A)
Sound Power Leve L
WA
108,6 dB(A)
Vibration Level
2,03 m/s
2
Weight 4,4 kg
