NuTone Hampton Series

SPECIFICATIONS
NOTES: Unless so stated, bulbs not
included. All measurements are in inches.
* Modular half-shelves.
Chart/Notes Key:
1. Style
B = Bi-View
L = Light
S = Single
SB = Slider
T = Tri-View
WM = Wall
Mirror
2. Mount Type
M = Mirror
R = Recessed
SM = Surface
Mount
R/SM = Recessed
or Surface
Mount
3. Hinge Type
B = Butt
C = Concealed
L = Leaf
P = Piano
PN = Pin
SC = Semi-concealed,
self-closing
hinge
4. Single Door Hinge
L = Left
R = Right
RV = Reversible
5. Cabinet Body
P = Polystyrene
S = Steel
SS = Stainless
W = Wood
6. Cabinet bottom always
provides an additional
storage level.
7. Shelf Material
AL = Aluminum
G = Glass
P = Polystyrene
S = Steel
W = Wood
SS = Stainless Steel
Model
No.
Pg
No.
Style
Name Frame Style
1
Overall Size
w h d
Mount
Type
2
Wall Opening
w h d Hinge Type
3
Single Door Hinge
4
Cab Body
5
Shelves
Qty
6
, Material
7
, Type
Matching
Light
Fixture
Rec.
Bulbs
Qty-Type
84024CHG 44 Styleline Chrome S 16 26 4
1
⁄2 R 14 24 3
1
⁄2 P RV S 3, G, Adjus. – –
840P24CHG 44 Styleline Chrome S 16 26 4
1
⁄2 R 14 24 3
1
⁄2 P RV S 3, G, Adjus. – –
840P34CH 44 Styleline Chrome S 16 36 4
1
⁄2 R 14 34 3
1
⁄2 P RV S 3, S, Adjus. – –
840P34CHD 44 Styleline Chrome S 16 36 4
1
⁄2 R 14 34 3
1
⁄2 P RV S 6*, P, Adjus. – –
840P34CHG 44 Styleline Chrome S 16 36 4
1
⁄2 R 14 34 3
1
⁄2 P RV S 3, G – –
84124CHLB 33 Lockbox Cabinet Chrome S 16 26 4
1
⁄2 R 14 24 3
1
⁄2 P RV S 2, S, Adjus. – –
850C 26 Soho Solid Cherry S 17
3
⁄16 27
7
⁄16 5
1
⁄4 R 14 24 3
1
⁄2 P RV S 3, G, Adjus. – –
850M 26 Soho Solid Maple S 17
3
⁄16 27
7
⁄16 5
1
⁄4 R 14 24 3
1
⁄2 P RV S 3, G, Adjus. – –
8570 29 Canterbury Solid Oak, Honey S 18 27
1
⁄8 5
1
⁄8 R 14 18 3
1
⁄2 P R S 2, P, Adjus. 76378 –
8572 29 Canterbury Solid Oak, Honey S 18 27
1
⁄8 5
1
⁄4 SM – – – P R S 3, P, Fixed 76478 –
860P30CH 35 Corner Chrome S 16 30 8 SM – – – P RV S 3, S, Fixed – –
860P30WH 35 Corner Chrome S 16 30 8 SM – – – P RV S 3, S, Fixed – –
860P36CH 35 Corner Chrome S 16 36 8 SM – – – P RV S 3, S, Fixed – –
867P30CH 35 Corner Frameless, Bevel S 16 30 8 SM – – – P RV S 3, S, Fixed – –
867P30WH 35 Corner Frameless, Bevel S 16 30 8 SM – – – P RV S 3, S, Fixed – –
867P36WH 35 Corner Frameless, Bevel S 16 36 8 SM – – – P RV S 3, S, Fixed – –
868M22XWHZ 21 Horizon Frameless, Bevel S 16 26 4
1
⁄2 R 14 24 3 P RV P 3, P, Adjus. – –
868M24WH 21 Horizon Frameless, Bevel S 16 26 4
1
⁄2 R 14 24 3 P RV P 3, P, Adjus. – –
868P18SS 21 Horizon Frameless, Bevel S 16 20 4
1
⁄2 R 14 18 3
1
⁄2 P RV SS 2, S, Adjus. – –
868P18WH 21 Horizon Frameless, Bevel S 16 20 4
1
⁄2 R 14 18 3
1
⁄2 P RV SS 3, S, Adjus. – –
868P24CH 21 Horizon Frameless, Bevel S 16 26 4
1
⁄2 R 14 24 3 P RV SS 3, S, Adjus. – –
868P24SS 38 Solid Stainless Steel Frameless, Bevel S 16 26 4
1
⁄2 R 14 24 3 P RV SS 3, SS, Adjus. – –
868P34CH 21 Horizon Frameless, Bevel S 16 36 4
1
⁄2 R 14 34 3 P RV S 3, S, Adjus. – –
868P34WH 21 Horizon Frameless, Bevel S 16 36 4
1
⁄2 R 14 34 3 P RV S 3, S, Adjus. – –
868P34WHLB 21 Horizon Frameless, Bevel S 16 36 4
1
⁄2 R 14 34 3 P RV S 3, S, Adjus. – –
868P34WHD 21 Horizon Frameless, Bevel S 16 36 4
1
⁄2 R 14 34 3 P RV S 6*, P, Adjus. – –
868P34WHG 21 Horizon Frameless, Bevel S 16 36 4
1
⁄2 R 14 34 3 P RV S 3, G, Adjus. – –
869P24WH 36 Flush Mount Frameless, Polished S 15 26 4
1
⁄2 R 14 24 4 P RV S 3, S, Adjus. – –
869P24WHG 36 Flush Mount Frameless, Polished S 15 26 4
1
⁄2 R 14 24 4 P RV S 3, G, Adjus. – –
869P34WHG 36 Flush Mount Frameless, Polished S 15 36 4
1
⁄2 R 14 34 4 P RV S 3, G, Adjus. – –
870 24 Baker Street Solid Oak, Honey S 18 27
1
⁄4 5
1
⁄4 R 14 18 3
1
⁄2 P RV S 2, G, Adjus. 70373 –
870P24WH 36 Flush Mount Frameless, Bevel S 15 26 4
1
⁄2 R 14 24 4 90 RV S 3, S, Adjus. – –
870P24WHG 36 Flush Mount Frameless, Bevel S 15 26 4
1
⁄2 R 14 24 4 90 RV S 3, G, Adjus. – –
870P34WH 36 Flush Mount Frameless, Bevel S 15 36 4
1
⁄2 R 14 34 4 90 RV S 3, S, Adjus. – –
870P34WHG 36 Flush Mount Frameless, Bevel S 15 36 4
1
⁄2 R 14 34 4 90 RV S 3, G, Adjus. – –
872BC 24 Baker Street Solid Oak, Honey S 18 27
1
⁄4 5 SM – – – P RV S 3, G, Adjus. 70273 –
8770 29 Grant Solid Oak, Honey S 16
1
⁄4 24
1
⁄4 5
3
⁄8 R 14 18 3
1
⁄2 P RV S 2, P, Adjus. – –
8772 29 Grant Solid Oak, Honey S 16
1
⁄4 24
1
⁄4 5
1
⁄2 SM – – – P RV S 2, P, Fixed – –
8773 29 Grant Solid Oak, Honey S 16
1
⁄4 22 4
5
⁄8 R 14 18 2
1
⁄2 B RV P 2, P, Fixed – –
8778 29 Grant Solid Oak, Honey S 16
1
⁄4 26
1
⁄4 5
3
⁄8 R 14 24 3
1
⁄2 P RV S 3, P, Adjus. – –
878BC 24 Baker Street Solid Oak, Honey S 18 27
1
⁄4 5
1
⁄4 R 14 24 3
1
⁄2 P RV S 3, G, Adjus. 70373 –
9000C 26 Mission Solid Cherry S 17
3
⁄16 33
7
⁄16 5
1
⁄8 R 14 24 3
1
⁄2 P R S 3, G, Adjus. – –
