NuTone Hampton Series

‑
56
8. Door(s) shipped not attached to cabinet
NOTES: Unless so stated, bulbs not
included. All measurements are in inches.
Chart/Notes Key:
1. Style
B = Bi-View
L = Light
S = Single
SB = Slider
T = Tri-View
WM = Wall
Mirror
2. Mount Type
M = Mirror
R = Recessed
SM = Surface
Mount
R/SM = Recessed
or Surface
Mount
3. Hinge Type
B = Butt
C = Concealed
L = Leaf
P = Piano
PN = Pin
SC = Semi-concealed,
self-closing
hinge
4. Single Door Hinge
L = Left
R = Right
RV = Reversible
5. Cabinet Body
P = Polystyrene
S = Steel
SS = Stainless
W = Wood
6. Cabinet bottom always
provides an additional
storage level.
7. Shelf Material
AL = Aluminum
G = Glass
P = Polystyrene
S = Steel
W = Wood
SS = Stainless Steel
Model
No.
Pg
No.
Style
Name Frame Style
1
Overall Size
w h d
Mount
Type
2
Wall Opening
w h d Hinge Type
3
Single Door Hinge
4
Cab Body
5
Shelves
Qty
6
, Material
7
, Type
Matching
Light
Fixture
Rec.
Bulbs
Qty-Type
H O 32490 21 Horizon Frameless L 24 4
1
⁄2 5
7
⁄8
For SM Cab
– – – – – – – – 3-60W G25/G40
H O 33090 21 Horizon Frameless L 30 4
1
⁄2 5
7
⁄8
For SM Cab
– – – – – – – – 4-60W G25/G40
H
O 33690 21 Horizon Frameless L 36 4
1
⁄2 5
7
⁄8
For SM Cab
– – – – – – – – 4-60W G25/G40
H
O 34890 21 Horizon Frameless L 48 4
1
⁄2 5
7
⁄8
For SM Cab
– – – – – – – – 5-60W G25/G40
H
O 42490 21 Horizon Frameless L 24 4
1
⁄2 2
1
⁄4
For R Cab
– – – – – – – – 3-60W G25/G40
H O 43090 21 Horizon Frameless L 30 4
1
⁄2 2
1
⁄4
For R Cab
– – – – – – – – 4-60W G25/G40
H O 43690 21 Horizon Frameless L 36 4
1
⁄2 2
1
⁄4
For R Cab
– – – – – – – – 4-60W G25/G40
H O 44890 21 Horizon Frameless L 48 4
1
⁄2 2
1
⁄4
For R Cab
– – – – – – – – 5-60W G25/G40
J1645P48CH 40 Commodore Mirrored Doors SB 48 32 4
1
⁄4 SM – – – – – S Cosmetic Box & Mirror, Mirrored Door
J1650P48CH 40 Commodore Styrene Doors SB 48 32 4
1
⁄4 SM – – – – – S Cosmetic Box & Mirror, Styrene Door
J169024CH 40 Commodore Styrene Doors SB 24
1
⁄4 8 4
1
⁄4 SM – – – – – S – Cosmetic Box, Styrene Door
J169030CH 40 Commodore Styrene Doors SB 30
1
⁄4 8 4
1
⁄4 SM – – – – – S – Cosmetic Box, Styrene Door
J169036CH 40 Commodore Styrene Doors SB 36
1
⁄4 8 4
1
⁄4 SM – – – – – S – Cosmetic Box, Styrene Door
J169048CH 40 Commodore Styrene Doors SB 48
1
⁄4 8 4
1
⁄4 SM – – – – – S – Cosmetic Box, Styrene Door
M18249301 44 Styleline Stainless S 18 24 5 SM – – – P RV S 3, G, Adjus. – –
M183693 44 Styleline Stainless S 18 36 4
3
⁄4 R 16 34 3
5
⁄8 P RV S 3, S, Adjus. – –
M18369301 44 Styleline Stainless S 18 36
1
⁄8 4
3
⁄4 SM – – – P RV S 3, G, Adjus. – –
M723385 21 Horizon Frameless S 16 22 3
1
⁄2 R 14 18 3 P RV S 3, S, Adjus. – –
PEM2424 40 Commodore Frameless WM 24 24
3
⁄16 SM – – – – – – – – Wall Mirror Only
PEM3024 40 Commodore Frameless WM 30 24
3
⁄16 SM – – – – – – – – Wall Mirror Only
PEM3036 40 Commodore Frameless WM 30 36
3
⁄16 SM – – – – – – – – Wall Mirror Only
PEM3624 40 Commodore Frameless WM 36 24
3
⁄16 SM – – – – – – – – Wall Mirror Only
PEM4824 40 Commodore Frameless WM 48 24
3
⁄16 SM – – – – – – – – Wall Mirror Only
PEM6036 40 Commodore Frameless WM 60 36
3
⁄16 SM – – – – – – – – Wall Mirror Only
RSC1000N 32 Security Standard Cabinet S 15
3
⁄4 26 3
1
⁄2 R 14 24 3
1
⁄2 P RV S 3, S, Adjus. – –
RSC2000N 32 Security Deluxe Large Cabinet S 15
3
⁄4 26 3
1
⁄2 R 14 24 3
1
⁄2 P L S 2, S, Adjus. – –
RSC3000N 32 Security Deluxe Small Cabinet S 15
3
⁄4 20 3
1
⁄2 R 14 18 3
1
⁄2 P L S 1, S, Adjus. – –
S368244OVWH 10 Metro Oval Frameless
–
24 35
7
⁄8 4
1
⁄2 R 14
1
⁄4 24 4 P RV S 3, G, Adjus. – –
S468244SS 4 Studio IV Frameless S 15 25
5
R 14
1
⁄4 24 4 SC RV SS 3, G, Adjus. – –
S468244WH 4 Studio IV Frameless S 15 25
5
R 14
1
⁄4 24 4 SC RV SS 3, G, Adjus. – –
S468344SS 4 Studio IV Frameless S 15 25
5
R 14
1
⁄4 34 4 SC RV SS 3, G, Adjus. – –
S468344WH 4 Studio IV Frameless S 15 25
5
R 14
1
⁄4 34 4 SC RV SS 3, G, Adjus. – –
SB22529 31 Vienna Chrome Trim L 24 4 5
1
⁄2
For SM Cab
– – – – – – – – 3-60W G25/G40
SB23129 31 Vienna Chrome Trim L 30 4 5
1
⁄2
For SM Cab
– – – – – – – – 4-60W G25/G40
SB330
8
42 Beauty Glide Stainless Steel Trim SB 31
3
⁄8 21
3
⁄8 5
1
⁄4 R 30
1
⁄4 19
3
⁄4 3
1
⁄2 – – S 2, G, Adjus. – –
V24
8
40 Commodore Stainless Steel Trim SB 24
1
⁄4 8
3
⁄4 4
1
⁄4 SM – – – – – S – Cosmetic Box, Mirrored Door
V30
8
40 Commodore Stainless Steel Trim SB 30
1
⁄4 8
3
⁄4 4
1
⁄4 SM – – – – – S – Cosmetic Box, Mirrored Door
V36 40 Commodore Stainless Steel Trim SB 36
1
⁄4 8
3
⁄4 4
1
⁄4 SM – – – – – S – Cosmetic Box, Mirrored Door
V48 40 Commodore Stainless Steel Trim SB 48
1
⁄4 8
3
⁄4 4
1
⁄4 SM – – – – – S – Cosmetic Box, Mirrored Door
VM224M
8
40 Commodore Stainless Steel Trim SB 24
1
⁄4 32 4
1
⁄8 SM – – – – – S Cosmetic Box & Mirror, Mirrored Door
VM224P
8
40 Commodore Stainless Steel Trim SB 24
1
⁄4 32 4
1
⁄8 SM – – – – – S Cosmetic Box & Mirror, Styrene Door
VM230M
8
40 Commodore Stainless Steel Trim SB 30
1
⁄4 32 4
1
⁄8 SM – – – – – S Cosmetic Box & Mirror, Mirrored Door
VM230P
8
40 Commodore Stainless Steel Trim SB 30
1
⁄4 32 4
1
⁄8 SM – – – – – S Cosmetic Box & Mirror, Styrene Door
VM236M
8
40 Commodore Stainless Steel Trim SB 36
1
⁄4 32 4
1
⁄8 SM – – – – – S Cosmetic Box & Mirror, Mirrored Door
VM236P
8
40 Commodore Stainless Steel Trim SB 36
1
⁄4 32 4
1
⁄8 SM – – – – – S Cosmetic Box & Mirror, Styrene Door
SPECIFICATIONS
