17
GB
chemicalsordetergentstothewater.
Insertthetrayintheoppositemannertoremoval.
MAKING A CUT
Adjustthe parallel guidefence tothe desiredwidth from the
bladeusingthescalerulesonthetablesurfaceforreference.To
adjustloosenthetwosecuringknobs(Pic5)(oneateachend).
N.B.: The scale rules are for reference only. For improved
accuracyitis advised that asecondaryruleshouldbe used.
Position the tile firmly against the rip fence and pass through
thebladeinasmoothaction.Donotforcethetiletobecuttoo
quickly.
MAKING A MITRE CUT
Follow the same procedure for a straight cut but employ the
mitre guide in conjunction with parallel guide fence (Pic 6).
Ensure that the tile is held firmly into the guide before making
thecut.
CUTTING WITH THE TABLE AT AN ANGLE
Loosenthetwotablesecuringknobs(frontandrear).Tiltthe
tabletothedesiredangleusingthescaleonthetable(Pic7).
Re-securethetableandmakethecutasbefore.
CHANGING THE BLADE
Warning! Disconnect the power supply before making
adjustmentsormaintainingthemachine.Toremovetheblade,
remove the side cover by removing the two securing screws
(Pic8),
Holdtheendofthebladearborandremovetheblade-securing
nutwithsuitablewrenches(Pic9).Ensurethatthearborand
flangesarecleanandre-fitthebladeintheoppositemanner
toremoval.
MAINTENANCE
When all cutting has been completed andbefore storing the
machine,itisadvisabletothoroughlycleanthemachine.Empty
thewatertrayandcleanawayanytileslurry.Cleanthetilecutter
withacleandrycloth.Itisalsoadvisabletogivethetableand
surface of the machine a light coating of automobile type wax
polish.
TECHNICAL SPECIFICATION
Voltage 220-240V~50Hz
Motor 600WS230min
No load speed 2950 min
-1
Diamond blade size 180mmx22.2mm
Max.cutat90° 34mm
Max.cutat45° 30mm
Tilting range 0x45°
Table size 386 x 397 mm
Sound pressure LpA91.8dB(A)
Sound power LwA104.98dB(A)
Weight 9,6 kg
