Assembly Instruction
STEP 2
Install left front leg (LF) (3) and left back leg (LB) (2)
to left side of counter top (1), use Eight (8) M6X15-A &
Eight (8) Flat Washer-B.
STEP 3
Install right front leg (RF) (5) and right back leg (RB)
(4) to right side of counter top (1), use Eight (8)
M6X15-A & Eight (8) Flat Washer-B.
Logo located at left side
of counter top
NOTE:
It is important to not fully
tighten the screws during
initial assembly of parts.
Wait until the 2nd mesh shelf
is installed before fully
tighten all screws on the cart
8
