Nuvo AccentPLUS Speaker - Page 14

The Rock
AccentPLUS
®
Rock
SYSTEM NV-AP18RS (Sandstone) NV-AP16RS
NV-AP18RG (Granite) NV-AP16RG
Description: 8" Rock Loudspeaker 6.5" Rock Loudspeaker
Mono Mono
Power Rating: 100W 50W
Impedance: 8 ohm 8 ohm
Efficiency: 91dB 1W/1M 88dB 1W/1M
Frequency Response: 45Hz-20kHz +/-3dB 60Hz-20kHz +/-3dB
Tweeter Crossover: 12dB 12dB
Woofer Crossover: 12dB 12dB
Dimensions (HxWxD): 13.5” x 13.5” x 1 2” 10.5” x 11” x 9”
(340mm x 340mm x 300mm) (165mm x 280mm x 226mm)
Weight: 16lbs (7.3kg) 9.7lbs (4.4kg)
WOOFER
Magnet: 20 oz (100 x 45 x 15mm) 10 oz (80 x 30 x 15mm)
Voice Coil: 1.0" (25mm) Polyimide Film .75” (19mm) Polyimide Film
Cone: 8” (205mm) Polypropylene 6.5” (165mm) Polypropylene
Surround: Butyl Rubber Butyl Rubber
Dust Cover: Polypropylene Polypropylene
TWEETER
Magnet: Neodymium Neodymium
Dome: PEI (Polyetherimide) 1” (25mm) PEI (Polyetherimide) 1” (25mm)
Type: Fixed Position Fixed Position
Specifications
