CONFIGURATIONS
06
DLP HDTV Connection Diagram
IR Emitter
PC
DLP
DVIUSB
HDMI Port
VESA 3-pin
stereo cable
3D Glasses
Emitter Port
DVI-to-HDMI
Cable
USB Cable
Attention: Check your DLP’s manual to see if there is a specific
HDMI port used to connect a PC to your HDTV. In addition, change
the input mode on the TV’s menu to PC or Computer to ensure the
TV can process the video signal correctly.
