Nvidia Mellanox ConnectX-6 Dx - Mechanical Drawings and Dimensions

61
Altitude
(Operational)
3050m
Environmen
tal
Airflow
Cable
Type
Hot Aisle
Heatsink to Port
Cold Aisle @35C
Port to Heatsink
Active Mode@
55C
Standby
Mode@45C
Active
Mode
Standby
Mode
Passive
Cable
500LFM 100LFM 300LFM 100LFM
Active
4.55W
Cable
800LFM @45C 600LFM @45C 300LFM 100LFM
Regulatory
Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
a.ConnectX-6 Dx adapters supplement theauto-negotiation specification to get better bit error rates
and longer cable reaches. This supplemental feature only initiates when connected to another
Mellanox Ethernetproduct.
b. Typical power for ATIS traffic load.
c. For both operational and non-operational states.
Board Mechanical Drawing and Dimensions
ConnectX-6 Dx SFP28/SFP56OCP 3.0 Mechanical Drawing and Dimensions
For the 3D Model of the card, please refer to 3D Models at http://www.mellanox.com/page/
3d_models.

All dimensions are in millimeters. The PCB mechanical tolerance is +/- 0.13mm.

