Nvidia RTX A2000 User Manual

1 Remove the current graphics driver installed on the host system.
2 Power down your system.
3 Unplug the power cord from the AC power source.
4 Remove the side panel from your system to gain access to the
motherboard.
Note: Reference your specific computer documents
for instructions on accessing the motherboard in
your computer.
03
HARDWARE
INSTALLATION

Nvidia RTX A2000 Specifications

General

GPU Architecture	Ampere
CUDA Cores	3328
Memory Type	GDDR6
Memory Interface	192-bit
Memory Bandwidth	288 GB/s
TDP	70 W
Interface	PCIe 4.0 x16
Display Outputs	4 x Mini DisplayPort 1.4a
DirectX Support	12 Ultimate
OpenGL Support	4.6
VR Ready	Yes
Memory Size	6 GB or 12 GB
NVENC	7th Generation
NVDEC	5th Generation
Boost Clock	1200 MHz
Max Resolution	7680 x 4320 at 60 Hz
