I2Cx_S field descriptions (continued)
Field Description
Any nonzero calling address is received that matches the address in the RA register.
The RMEN bit is set and the calling address is within the range of values of the A1 and RA registers.
NOTE: For the RAM bit to be set to 1 correctly, C1[IICIE] must be set to 1.
Writing the C1 register with any value clears this bit to 0.
0 Not addressed
1 Addressed as a slave
2
SRW
Slave Read/Write
When addressed as a slave, SRW indicates the value of the R/W command bit of the calling address sent
to the master.
0 Slave receive, master writing to slave
1 Slave transmit, master reading from slave
1
IICIF
Interrupt Flag
This bit sets when an interrupt is pending. This bit must be cleared by software by writing a 1 to it, such as
in the interrupt routine. One of the following events can set this bit:
One byte transfer, including ACK/NACK bit, completes if FACK is 0. An ACK or NACK is sent on the
bus by writing 0 or 1 to TXAK after this bit is set in receive mode.
One byte transfer, excluding ACK/NACK bit, completes if FACK is 1.
Match of slave address to calling address including primary slave address, range slave address,
alert response address, second slave address, or general call address.
Arbitration lost
In SMBus mode, any timeouts except SCL and SDA high timeouts
I2C bus stop detection if the STOPIE bit in the Input Glitch Filter register is 1
NOTE: To clear the I2C bus stop detection interrupt: In the interrupt service routine,
first clear the STOPF bit in the Input Glitch Filter register by writing 1 to it, and
then clear the IICIF bit. If this sequence is reversed, the IICIF bit is asserted
again.
0 No interrupt pending
1 Interrupt pending
0
RXAK
Receive Acknowledge
0 Acknowledge signal was received after the completion of one byte of data transmission on the bus
1 No acknowledge signal detected
38.3.5 I2C Data I/O register (I2Cx_D)
Address: Base address + 4h offset
Bit 7 6 5 4 3 2 1 0
Read
DATA
Write
Reset
0 0 0 0 0 0 0 0
Chapter 38 Inter-Integrated Circuit (I2C)
KL25 Sub-Family Reference Manual, Rev. 3, September 2012
Freescale Semiconductor, Inc. 695
