22
1
/3
2
/3
9
Hold model securely when starting
10
Setting the throttle
Starter
Assistant should hold the model so that it cannot
move forward when the engine starts.
Be careful not to be hit by propeller!
Fully opened position
Fully closed position
Set at this Position.
Assistant
Glowplug battery.
Place as far to the
rear as possible.
11
Heat glowplug
Starting battery
Connect battery leads as
shown (polarity is immaterial.)
23
12
Apply electric starter
Check that the throttle is one-third open from
the fully closed position. Bring the starter into
contact with the spinner nut or spinner and
depress the starter switch for one or two
seconds. Repeat if necessary. When the
engine fires, withdraw the starter immediately.
Attention: Never place your finger over the
carburettor intake when applying the
starter. Such an action will cause an excess
quantity of fuel to be drawn into the
cylinder and result in hydraulic lock that
may damage the engine.
