7
Installation Instructions
step 12: Re-connect the board
connections. Plug the 2-pin ozone
connector into the designated receiver.
step 13: Re-install the front valve cover
to the backplate. Plug the control valve
transformer into a 110-volt power supply.
Continue to programming procedures on
the following pages.
step 11: Replace the board bracket into
the backplate until it snaps into place. If
the generator kit came with a new board,
install it into the board bracket, making
sure it clicks into place. If no new board is
supplied, reinstall the previously removed
board.
