OAV P30 - Page 39

P30
(optional-two motor)
ASSEM02-5
ITEM PART NO NOTE
2 994810
3 207265
5 996002
6 994808
7 206376 R
9 NF061000
10 WF061310
11 200867
12 200867A-1
15 206377 R
16 SJ060200
994809
994862
OPT. (D30P2)
18 150527
20 N
H081300
21 WS080000
22 WF081818
23 709421
Strain Relief PG20 4
Lock Washer M8 4
Washer M8x18 4
Pad 2x300x7.5(M/M) 5
Hex Nut M8 4
17
Power Switch ZH-HD-2 1
Power Switch 1
Plate 1
Button Head Screw M6*10 6
Electric.Panel 400V 3~ Elec. Btake 1
Plate 1
Hex Nut M6 4
Washer
M6xψ13
4
Emergency Stop Button 1
Plate 1
Label 1
Pilot Lamp
YK.24V φ22 (W)
1
SIZE Q`TYPARTS NAME
Button Switch HY57(1A1B) 2
