Page 17
Issue Solution
Thin (out
of phase)
sound
This is usually caused when two pickups are out of phase with each other.
Reverse the connector positions of the hot and ground wires from one of the
pickups.
Before you make the change, take some time to work out which pickup is
least likely to interfere with other switch positions. If you have just installed a
new pickup, change this one.
What colour
wires go
where?
Pickup manufacturers use their own colour coding systems. Check the pickup
builder’s instructions & compare to the instructions in this booklet.
Also see a list of popular pickup codes here obsidianwire.com/install-help
Custom
4-Way for
Tele - Same
sound in all
positions
Ensure the neck pickup ground & cover ground wires are in the correct
slots.
Ensure the link between your pickups ground wire & the cover ground wire
has been removed.
