Obsidian Wire
Ōtautahi, Christchurch
New Zealand
Questions?
obsidianwire.com/install-help
Legal Disclaimer
The terms “Strat®”, “Tele®”, “Precision Bass®”, &
“Jazz Bass®” are registered trademarks of Fender
Musical Instruments Incorporated (FMIC). We use
these terms to describe the compatibility of our
pro-wired electronics only. ObsidianWire is in NO
way affiliated with or supported by FMIC.
The term “Les Paul®” is a registered trademark
of Gibson Guitar Corp. We use these terms to
describe the compatibility of our Pro-wired elec-
tronics only. ObsidianWire is in NO way affiliated
with or supported by Gibson Guitar Corp.
Contents
Install Instructions .......Foldout
Diagrams
Strat
®
Vintage / Blender / 7-Way
4
Custom HSS
5
Custom HSH
6
Custom HH
7
Tele
®
Custom 4-Way
8
Custom 4-Way Pickup Mod
9
Traditional Vintage
10
Custom Nashville 7-Way
11
Bass
Jazz Bass
®
12
Precision Bass
®
13
Les Paul
®
2 Conductor Pickups
14
4 Conductor Pickups
15
Troubleshooting 16
Warranty 18
About Us 19
