#5: Check to make sure the hole
locations in the Platform are clear
of pool wall and supports. Drill two
5/16 holes through the Platform
and pool ledge. Fasten the ladder
platform to the pool ledge using two
¼-20 x 2-1/4” bolts, ¼-20 hex nuts.
OUTSIDE TREADS MUST
BE IN THE UP POSITION
AND LOCKED AT ALL
TIMES WHEN POOL IS
NOT IN USE.
- 5 -
Step #5 continued
#4: Position the ladder over the pool step with the Mounting Blocks sitting at on the top tread. Center the
ladder side-to-side and align the back of the Mounting Blocks next to the groove in the back of the Platform as
shown. Attach using four #10 x 3/4” self-tapping screws in each Mounting Block.
#6: When the pool is not in use,
rotate the Swing-up Ladder to the
up position and secure it in place
with the padlock as shown.
