OCEANair DRYROLL - Page 3

DRYROLL
INSTALLATION INSTRUCTIONS
RECESSED MOUNTING TEMPLATE
www.oceanair.co.uk
)RUIXUWKHULQIRUPDWLRQRULQVWDOODWLRQDVVLVWDQFHSOHDVHFRQWDFW\RXUORFDO2FHDQDLU'LVWULEXWRU
www.oceanair.co.uk/distributors.
2FHDQDLU0DULQH8.  WHFKVXSSRUW#RFHDQDLUFRXN
2FHDQDLU0DULQH86  LQIR#RFHDQDLUPDULQHFRP
75 mm
(3")
Outer edge of DRYROLL frame
Outer edge of DRYROLL frame
Cutting line
Cutting line
Actual size
Actual size
Ensure there is a minimum of
75 mm (3") clearance inside the wall

4
4
4
4
Ensure the template is printed at the correct size by measuring the scale bar which should be 200mm (7 7/8") from end to end.
