Ocular LTE - Page 5

Installation Guide
Place REFERENCE PAPER
on wall
Hammer the
30mm PLASTIC BOLTS
into the holes
Take down the
REFERENCE PAPER
from the wall
Mount charger
onto the PLATE
This is what the charger will look like
after installation and connection to
the isolation switch.
You can put the HOOK and HOLDER
anywhere
Fix the PLATE
with 30mm SCREWS
on the wall
Drill the holes
according to the
REFERENCE PAPER
Wall
Tear o the protector
03
Isolation Switch
