OEM Tools MANUAL FLUID EXTRACTOR - Page 4

4
Operating Instructions and Parts Manual 24397
MANUAL FLUID EXTRACTOR
07/14
2014 ©OEM-TOOLS
Figure Description Quantity
24397-1
Main Suction
Tube
1
24397-2 Suction Tube 1
24397-3 Dipstick Tube 1
24397-4 Pump Handle 1
24397-5 Reservoir 1
24397-6 Float Assembly
(Not Shown)
1
24397-7 Base 1
NOTE
Not all components of the Manual Fluid
Extractor are replacement items, but are
illustrated as a convenient reference for
location and position in the assembly
sequence.
(1)
Main
Suction
Tube
(2)
Suction Tube
(3)
Dipstick Tube
(5)
Reservoir
(7)
Base
(4)
Pump Handle
