EN-6 RS232 Interface
RS232 OUTPUT
With the interface installed the balance will operate in several ways according to the
settings.
Print format can be switched by xFMT user command (see command table in
RS232 INPUT section).
New Scout Print Format (Default Format):
Output String (Non Check Weighing Applications):
[weight] 11 characters (right justified)
[space] 1 character
[unit] 5 characters (right justified)
[space] 1 character
[stability indicator] 1 character; "?" when unstable, space when stable
[space] 1 character
[T/N/G/PT] 2 characters (right justified)
[Term] 2 characters
Note: All of the fields have fixed length.
Output example:
*****
192.21_****g_*_**
*******
0.01_****g_?_**
*******95.0_****g_*_*N
******169.6_****g_*_*G
*******95.0_****g_*_*N
*******74.6_****g_*_*T
A.Print: off; Stable: off
Stable reading
unstable reading
A.Print: off; Stable: on
Content / Result -> on
Content / Gross -> on
Content / Net -> on
Content / Tare -> on
Output String (Check Weighing Application):
[weight] 11 characters (right justified)
[space] 1 character
[unit] 5 characters (right justified)
[space] 1 character
[stability indicator] 1 character; "?" when unstable, space when stable
[space] 1 character
[T/N/G/PT] 2 characters (right justified)
[space] 1 character
[application status] 6 characters (right justified)
[Term] 2 characters
Example:
