OHIOSTEEL 3040P - Assembly Instructions Continued; Attach Axle Holders; Attach Latch Angle; Insert Axle and Attach Components

* NOTE: LOOSELY TIGHTEN
BOLTS AT THIS TIME
19
20
3
25
8
19
20
11
9
Attach two axle holders to the axle supports as shown using the supplied hardware
Attach latch angle to drawbar assembly with supplied
hardware as shown
Insert axle into undercarriage halfway as shown.
Attach spacer, drawbar assembly, and spacer
4
Assembly Instructions
4
6
5
