OHIOSTEEL 60T - Assembly Instructions; Step 1: Attach Side Angle to Bar Assembly; Step 2: Slide Side Bars onto Axle; Step 3: Attach Hitch Assembly

1
2
Flange faces in
57 6
A
3
8
9
4
5
67
10
11
2
1
3
Attach Side Angle (1) to Bar Assembly(2) using 3/8" Bolts (5), Lockwashers (6) and 3/8"
Nuts (7). Note flange of pressed bearing faces in.
Attach Hitch Assembly (4) to side bars using 3/8" Bolts (5), Lockwashers (6) and 3/8"
Nuts (7). Install Hitch Pin (10) and Hairpin Cotter (11) as shown.
Slide both side bars over axle with flanges of the bearing towards the inside of
the roller head, add Washers (8) and lock in place by inserting and spreading
ends of Cotter Pins (9).
4
Assembly Instructions
