Oki APR-5000 - Page 20

www.okinternational.com - 19 - P/N 7000-1370, Revision B
Notes
Physically pull
camera out.
Check mark
moves from
Camera Home
switch to
Camera EOT
switch.
Physically pull
camera out.
Check mark
toggles from
Camera Home
switch to
Camera EOT
switch.
Physically press
the head X and Y-
axis switches on
the APR-5000
heater head.
Check mark must
turn on
momentaril
y
.
