45641001TH Rev.1

5-31 /

Oki Data CONFIDENTIAL

[EA40] Side cover open jam

Classiﬁcation Error content

Paperjaminnishersection Jam occurred because ﬁnisher’s side cover was opened while ﬁnisher

was transporting paper.

Check item Measures

Transport path Ifthereispaperinthepapertransportpath,removethepaper.

Side cover Close the cover if it is open.

Door switch • Switchcheck(SW2)

• Connectorcheck(P2-12,P2-13)

• Harnesscheck

Finisher control PC board • Boardcheck

• Connectorcheck(J2)

• Harnesscheck

Parts to be replaced Remark

Door switch

Finisher control PC board

[EA50] Stapling jam

Classiﬁcation Error content

Paperjaminnishersection Staplejamoccurredatstapler.

Check item Measures

Stapler • Removethestaplecartridge,removeanyjammedstaples,installthe

staple cartridge.

• Connectorcheck(P9-1,P10-1)

• Harnesscheck

Finisher control PC board • Boardcheck

• Connectorcheck(J9,J10)

• Harnesscheck

Parts to be replaced Remark

Stapler

Finisher control PC board
