45641001TH Rev.1

9-2 /

Oki Data CONFIDENTIAL

9.1.3 Backup ﬁles

The following ﬁles are saved in the root directory of the USB device by backing up.

Filename Remark

Modelname_MFPSerialNo_yyyy-MM-dd_

hh-mm

E.g.:Whenbackupwasperformedat13:59on

October1st,2010.

T290_CUK911379_2010-10-01_13-59

9.1.4 Cloning procedure

[A] Backup procedure

(1) Pressthe[ON/OFF]buttontoshutdowntheequipment.

(2) Connect the USB device [1] to the USB port [2] on the right upper cover.

[2]

[1]

Fig. 9-3

Notes:

Backing up cannot be performed with multiple USB device [1] connected at the

same time.

(3) TurnthepowerONwhilepressing[6]andthe[CLEAR]buttonsimultaneously.

(4) When“SRAMClearMode”appearsontheLCD,keyin[0]toselect“0.SetSerial

Number” and then press the [START] button.

(5) Keyintheserialnumberonthelabelattachedtotherearcoveroftheequipment,and

thenpressthe[OK]button.

(6) “SerialNumberSettingcompleted”isdisplayed.

(7) Turn the power OFF.

(8) TurnthepowerONwhilepressingthe[5]and[9]buttonssimultaneously.

(9) Enterthepassword,andthenpressthe[OK]button.

 (IfthepasswordisnotsetforService,pressthe[ENTER]buttonwithoutentering

anything.)

(10)Select“1.BackupSRAMDatatoUSB”,andthenpressthe[START]button.

(11) Enter a password (max. 15 characters) set for the backup data.

(12)“BackupSuccessfullydoneRestoretheMFP”isdisplayedontheLCDscreenwhen

the backup has been properly completed.

(13)Pressthe[ON/OFF]buttontoshutdowntheequipment.
