Oki MB760dnfax Service Manual

45641001TH Rev.1
10-2 /
Oki Data CONFIDENTIAL
2. Connector on the SYS board: CN110 (JST-made B7B-PH-SM4) (Coin Controller)
Pin
No.
I/O Signal name Function Voltagelevel Remarks
GQ-
1260
1 Out LARGE/
SMALL
Paper size Signal Open Collector L:Largesize In use
2 Out FULL
COLOR
Full color mode
Signal
Open Collector L:Fullcolor In use
3 Out TWN/MON
COLOR
Twin color / Mono
color Mode Signal
Open Collector L:Twincolors In use
4 Out B/W Black mode Signal Open Collector L:Black In use
5 Power N.C.(5VA) 5Vline DC5.0V At the sleep
mode: ON
-
6 GND GND Signal Ground - In use
7 - N.C. - - -
