4. SETTING / ADJUSTMENT
4.1 Image Related Adjustment
4.1.1 AdjustmentOrder
Thischaptermainlyexplainstheproceduresforimagerelatedadjustment.Inthefollowing
diagram,thesolidlineswitharrowleadtoessentialadjustments,whilethedottedlinesleadto
adjustmentstobeperformedifnecessary.
Parts to be replaced
Drum unit Transfer blet unit
4.1.3 Image dimensional adjustment
Item
Code in 05 mode
in the copy/printer/fax function
Order
1
2
7000
7001 (*2)
Code in 05 mode
7165 (*1)
Adjust the image quality if necessay. Chapter 4.2, 4.3, 4.4, 4.5
END
Item to be adjusted
4.2.1 Automatic gamma adjustment
*1: Use [10] + [FAX] test pattern.
*2: Adjustment can be done only for enlarging image.
Image dimensional adjustment
Fig. 4-1
To Next Page
