Oldsmobile Bravada 2002

6-60
Micro Relays Usage
37 Blank
38 Rear Window Washer
39 Fog Lamps
40 Horn
41 Fuel Pump
42 Windshield Wipers/Washer
43 High
-Beam Headlamp
44 Air Conditioning
Solid State
Relays
Usage
45 Cooling Fan
46 HDM
Mini Relay Usage
47 Starter
Miscellaneous Usage
48 Instrument Panel Battery
49 Fuse Puller
Rear Underseat Fuse Block
The rear underseat fuse block is located under the rear
seat on the driver’s side of the vehicle.
