1-18 d-COLOR MF654/MF554/MF454/MF364/MF304/MF254
Space requirements
1
1.6
1.6 Space requirements
To ensure that machine operation, consumables replenishing, part replacement, and regular maintenance
can easily be performed, adhere to the recommended space requirements detailed below.
d-COLOR MF654/MF554/MF454
NOTICE
Be sure to allow a clearance of 8 inches (200 mm) or more at the back of this machine for the ventilation duct.
d-COLOR MF654/MF554/MF454 + PC-215 + FS-537+ SD-512 + RU-513 + PI-507 +
LU-207
97-1/2 (2477)
24-11/16
(627)
49
(1244)
49-7/8 (1267)
61-7/16 (1560.5)
37-1/2
(953)
13-15/16
(353.5)
16-9/16
(420)
33-3/8
(847)
10
(254)
17-13/16
(452)
Unit: inch (mm)
15/16 (24)
5-1/8 (130)
d-COLOR MF654/MF554/MF454 + PC-215 + FS-536 + SD-511 + RU-513 + PI-507 +
LU-302
Unit: inch (mm)
82-3/8 (2092)
20-13/16
(528)
38-11/16
(982)
49-7/8 (1267)
61-7/16 (1560.5)
37-1/2
(953)
13-15/16
(353.5)
16-9/16
(420)
33-3/8
(847)
10
(254)
17-13/16
(452)
4-1/2 (115)
9/16 (15)
d-COLOR MF 554/MF454 + PC-215 + FS-533 + MK-730 + CU-102 Unit: inch (mm)
52-1/16 (1322)
6-11/16
(170)
24-3/16
(615)
49-7/8 (1267)
61-7/16 (1560.5)
37-1/2
(953)
13-15/16
(353.5)
16-9/16
(420)
33-3/8
(847)
10
(254)
11-5/8
(295)
9-15/16
(252)
