Microsoft Windows> 61
N
ETWORK
P
RINTER
S
ETTINGS
There are two configurable items under NetBEUI within the
printer. These can be configured using the standard set-up utility
described in Chapter 1.
Although there are some differences in configuration options
between the various Windows platforms, the procedure for
printing using NetBEUI is the same.
Please ensure the NetBEUI protocol has been installed in
Windows. This can be confirmed by checking the network
settings. If NetBEUI has not been installed please refer to the
section below.
The relevant Windows installation CD-ROM may be required and
you should follow the on-screen dialogue box prompts.
W
INDOWS
2000
1. Click the [Start] button, select [Settings] and then click
on [Network and Dial-up Connections].
2. Double-click the [Local Area Connection] icon. In the
[Local Area Connection Status] dialogue box, click the
[Properties] button.
3. In the [Local Area Connection Properties] dialogue box, if
the [NetBEUI Protocol] is not listed, click the [Install]
button.
4. In the [Select Network Component Type] dialogue box,
select [Protocol] and click the [Add...] button.
5. In the [Select Network Protocol] dialogue box, select
[NetBEUI Protocol] and click the [OK] button.
6. Click the [Close] button in the [Local Area Connection
Properties] dialogue box.
COMPUTER NAME NAME ASSIGNED TO THE PRINTER
Workgroup
PrintServer
1
1. Although the workgroup name can be changed, it is recommended
that it remains as PrintServer.
Comment User definable description
