Thank you for purchasing our 12ft Octagon Bayside Gazebo Kit.
Please take the time to identify all the parts prior to assembly.
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 2
Parts List
A. Floor Joist Section (Page 4-11)
1 - 5 1/4” - Diameter Octagon Core Block
8 - 1 1/2” x 5 1/2” x 68 7/16” - Main Floor Joist
8 - 1 1/2” x 5 1/2” x 23 13/16” - “T” Post Mount Plate / Main Floor Joist
8 - 1 1/2” x 5 1/2” x 53 1/16” - Mid Floor Joist
8 - 1 1/2” x 5 1/2” x 13 1/8” - Interior Core Brace - angle cut on ends
8 - 1” x 5 1/2”w x 58 3/8” - Outer Rim Joists
8 - 3 1/2” x 3 1/2” x 91 1/4” - Posts - Angle Cut on Top / Drilled on Bottom
1 - Plywood Post Spacing Template - Angle cut on ends
B. Rafter Section (Page 12-14)
8 - 3 1/2” x 3 1/2” x 74 1/8” - Corner Rafters (30 & 22 1/2 degree cut)
8 - 3 1/2” x 3 1/2” x 70” - Mid Rafters (31 degree cut both ends)
8 - 1 1/2” x 6” x 14 7/8” - Octagon SkyBox (Cut,Dado and Drilled)
C. Rail Section (Page 15-19)
7 - 53 7/8” x 36” - Hand Rail Section
14 - 5/8” x 3 1/8” x 40” - Hand Rail End Caps - Dog Ear and Router edges.
8 - 53 7/8” x 10” - Upper Rail Section
8 - 5/8” x 3 1/8” x 15 1/4” - Upper Rail End Caps -Right Side (Angle Cut One End with Hole)
8 - 5/8” x 3 1/8” x 15 1/4” - Upper Rail End Caps -Left Side (Angle Cut One End with Hole)
D. Floor Section (Page 20-23)
8 - Pre-assembled Deck Floor Panels - Triangular Shaped
8 - 1” x 5 1/2” x 60 1/2” - Perimeter Deck Board- notched for Post
8 - 1” x 5 1/2”w x 14 1/8” - 2nd to last Deck Board
8 - 1” x 5 1/2”w x 9 1/2” - Last Deck Board
1 - 1” x 12” - Octagon Center Deck Piece
E. Roof Section (Page 24-29)
16 - Roof Panels (8 left / 8 right)
16 - 1 1/2” x 5 1/2” x 22 5/8” - Corner Brackets - 8 left / 8 right
8 - Facia Boards - 1” x 4 1/2” x 64 1/2” long - Angle Cut on Ends
F. Cupola Parts List (Page 30-34)
8 - Side Rail Sections
1 - Small Core Block- Octagon
8 - 1 1/2” x 1 1/2” x 24” - Rafter - (Angle Cut Both Ends)
8 - 3/4” x 1 1/2” x 18” - Facia
8 - Small Roof Panels
24 - Cupola Ridge Caps (2 1/2’ wide “V” shaped) 8 - 16” long / 8 - 14 1/2” long / 8 1/2” - 10” angle ends
1 - Top Cap & Ball Top
G. Miscellaneous Section (Page 35-37)
48 - Filler Shingles- Main - 5 1/2” x 16”
8 - Filler Shingles - Top - 5 1/2” x 8 1/4”
8 - Facia Corner Detail Plates (Small)
8 - Rim Joist Corner Detail Plates (Large)
88 - Ridge Cap Shingles - (8 caps cut to 10” long for row against cupola)
