Thank you for purchasing a 6x6 Maximizer Storage Shed
Please take the time to identify all the parts prior to assembly.
Parts List:
1. Floor Section
2 - 35” x 75” - Floor Frames - 1A
4 - 1 1/2” x 3 1/2” x 72” - Floor Joists - 1B
3 - 1 1/2” x 3 1/2” x 70” Floor Runners - 1C
2 - 5/8” x 34 7/8” x 74 7/8” - Plywood Floor - 1D
2. Wall Section
6 - 35” x 75” - Wall Panels - (Walls with Bottom Plates Unattached) - 2A
6 - 1 1/2”x 2 1/2” x 35” - Bottom Wall Plates - 2B
Door Jambs & Header
2 - 2 1/2” x 3 3/4” x 73” - Vertical Door Jamb with Cleat attached - 2C
1 - 2” x 2 1/2” x 71 1/2” - Door Header - 2D
Top Wall Plates
2 - 3/4” x 2 1/2” x 75” - Side Top Plates (Angle cut on ends) - 2E
2 - 3/4” x 2 1/4” x 65” - Front & Rear Top Plates ( Angle cut on 1 edge) - 2F
2 - 1 1/2” x 5 1/2” x 5 1/2” Front Triangular Corner Brackets - 2G
Gable Walls
2 - Gable Walls - Triangular Shaped - 2H
Misc. Wall
1 pc - Spare Wall Siding - 2I
3. Rafter and Roof Section
12 - 1 1/2” x 3 1/2” x 45” - Roof Rafters with angled ends - 3A
2 - 3/4” x 4 1/2” x 70” - Roof Ridge Boards - 3B
2 - 1/2” x 4 1/2” x 70” - Soffits - 3C
1 - 3/4” x 3 1/2” x 48” - Roof Gusset - 3D
2 - Left Roof Panels 41” (Shingles overhanging plywood on left side) - 3E
2 - Right Roof Panels 41” (Shingles overhanging plywood on right side) - 3F
4 - Roof/Facia Cleats - 3/4” x 1 1/2” x 42” - 3G
6 - Long Roof Filler Shingles - 3H
2 - Short Roof Filler Shingles - 3I
12 - Roof Ridge Caps - 3J
4. Miscellaneous Trim Section
2 - 3/4” x 4 3/8” x 79” - Door Trim - 4A
1 - 3/4 ” x 4 1/2” x 64” - Front Bottom Skirting - 4B
6 - 1/2” x 4 1/2” x 34 3/4” - Side and Rear Bottom Skirting - 4C
2 - 3/4” x 2 1/2” x 75” - Rear Filler Trim - 4D
2 - 1/2” x 4 1/2” x 77 1/2” - Side Rear Wide Trim - 4E
3 - 1/2” x 2 1/2” x 79” - Narrow Trim (Rear Wall) - 4F
2 - 1/2” x 4 1/2” x 77 1/2” - Side Front Wide Trim - 4G
4 - 1/2” x 4 1/2” x 37 7/8” - Horizontal Gable Trim - 4H
2 - 1/2”x 2 1/2” x 77 1/2” - Narrow Trim (Side Walls) - 4I
2 - Horizontal Gable Detail Plates - 4J
4 - 3/4” x 3 1/2” x 46” - Side Facia - Angle cut both ends - ( 2 right / 2 left) - 4K
2 - 3/4” x 3 1/2” x 79 1/2” - Front and Rear Facia - 4L
2- Pentagon Facia Plate - 4M
1 - Left Side Door - 4N
1 - Right Side Door - 4O
2 - Cedar Shingles used for Shims - 4P
1 - 1/2” x 1 1/4” x 64” - Above Door Trim - 4Q
1 - 1 1/2” x 2 1/2” x 64” - Horizontal Door Stop with Dado cut - 4R
1 - 3/4” x 2 1/2” x 62 1/2” - Door Threshold - 4S
1 - 1/2” x 2 1/2” x 71” - Interior Door Flange - 4T
2 - 1/2” x 2 1/2” x 71” - Interior Door Stops - 4U
* Note - Trim pieces are graded best face on the rough side. Use this side out.
