Thank you for purchasing our 10ft Bayside Gazebo Kit.
Please take the time to identify all the parts prior to assembly.
Parts List:
A. Floor Section (Page 4-11)
1 - 5 1/4” - Diameter Octagon Core Block
8 - 1 1/2” x 5 1/2” x 55 1/4” - Main Floor Joist
8 - 1 1/2” x 5 1/2” x 24 3/4” - “T” Post Mount Plate / Main Floor Joist
8 - 1 1/2” x 5 1/2” x 42 3/8” - Mid Floor Joist
8 - 1 1/2” x 5 1/2” x 12” - Interior Core Brace - angle cut on ends
8 - 1” x 5 1/2” x 48 3/4” - Outer Rim Joists
8 - 3 1/2” x 3 1/2” x 91 1/4” - Posts - Angle Cut on Top / Drilled on Bottom
1 - Plywood Post Spacing Template - Angle cut on ends
B. Rafter Section (Page 12-14)
8 - 3 1/2” x 3 1/2” x 58 1/8” - Rafters (Angle Cut on each end)
8 - 1 1/2” x 6” x 14 7/8” -Octagon SkyBox Pieces (Cut,Dado and Drilled)
C. Rail Section (Page 15-19)
7 - 43 5/8” x 36” - Hand Rail Section
14 - 9/16” x 3 1/8” x 40” - Hand Rail End Caps - Dog Ear and Router edges.
8 - 43 5/8” x 10” - Upper Rail Section
8 - 9/16” x 3 1/8” x 15 1/4” - Upper Rail End Caps -Right Side (Angle Cut One End with Hole)
8 - 9/16” x 3 1/8” x 15 1/4” - Upper Rail End Caps -Left Side (Angle Cut One End with Hole)
8 - 1 1/2” x 3 1/2” x 55” - Mid Rafters
D. Floor Section (Page 20-23)
8 - Pre-assembled Deck Floor Panels - Triangular Shaped
8 - 1” x 5 1/2” x 50 5/8” - Perimeter Deck Board- notched for Post
8 - 1” x 5 1/2” x 13 1/4” - 2nd to last Deck Board
8 - 1” x 5 1/2” x 8 5/8” - Last Deck Board
1 - 1” x 10” - Octagon Center Deck Piece
E. Roof Section (Page 24-28)
8 - Large Roof Panels
8 - Facia Boards - 1” x 4 1/2” x 54 5/8” - Angle Cut on ends
16 - 1 1/2” x 5 1/2” x 22 5/8” - Corner Brackets - 8 left / 8 right
F. Cupola Section (Page 29-33)
8 - Side Rail Sections - 14 7/8” wide
1 - Small Core Block- Octagon
8 - 1 1/2” x 1 1/2” x 24” - Rafter (angle on both ends)
8 - 3/4” x 1 1/2” x 18” - Facia
8 - Small Roof Panels
24 - Cupola Ridge Caps (2 1/2’ wide “V” shaped) 8 - 16” long / 8 - 14 1/2” long / 8 - 10 1/2” angle ends
1 - Top Cap & Ball Top
G. Miscellaneous Section (Page 34-36)
8 - Facia Corner Detail Plates (Small)
8 - Rim Joist Corner Detail Plates (Large)
80 - Cedar Roof Ridge Cap Shingles
(8 need to be trimmed for last row)
