Thank you for purchasing our 12x12 Sunshed Garden Shed.
Please take the time to identify all the parts prior to assembly.
A. Floor Section
3 - 45 1/2” x 75” - Floor Joist Frames (Interior Joist Unattached)
3 - 45 1/2” x 66 1/2” - Floor Joist Frames (Interior Joists Unattached)
6 - 1 1/2” x 3 1/2” x 71 7/8" - Floor Joists
6 - 1 1/2” x 3 1/2” x 63 1/2" - Floor Joists
3 - 45 3/8” x 74 7/8” - Floor Plywood
3 - 45 3/8” x 66 3/8” - Floor Plywood
10 - 1 1/2” x 3 1/2” x 76 1/2 & 60” - Floor Runners
B. Wall Section
Main Wall Panels
4 - 45 1/2” x 75” - Solid Wall Panels
4 - 1 1/2” x 2 1/2” x 45 1/2” - Bottom Wall Plates
4 - 45 1/2” x 75”- Window Wall Panels
3 - 45 1/2” x 75” - Double Window Walls
1 - 12” x 73” - Narrow Wall Panel
2 - 45 1/2” x 9” - Wall Extendors
2 - 46 1/4” x 9” - Angled Left Wall Extendors
2 - 46 1/4” x 9” - Angled Right Wall Extendors
Window Inserts
6 Small Window Inserts
4 Regular Window Inserts
Door, Door Jamb, Header & Door Stops
1 - 1 1/2” x 3 1/4” x 73” - Vertical Door Jamb
1 - 2” x 3 1/4” x 45 1/2” - Door Header (Dado)
2 - 1/2” x 2 1/2” x 72” - Interior Vertical Door Stops
1 - 1/2” x 2 1/2” x 36”- Interior Horizontal Door Stop
1 - 31 1/2” x 72” - Dutch Door - 2pcs (42” and 30” high)
Gable Walls
2 - Left Hand Gables - Triangular shaped
2 - Right Hand Gables - Triangular shaped
Top Wall Plates
4 - 3/4” x 2 1/4” x 65 3/4” - Sides - 22 1/2 degree cut on edge
4 - 3/4” x 2 1/2” x 70 3/4” - Front and Rear - Angled on end
C. Rafter Section
18 - 1 1/2” x 3 1/2” x 80 7/8” - Rafters - angled on both ends
3 - 3/4” x 8 1/2” x 45 1/2” - Ridge Boards
1 - 3/4” x 8 1/2” x 64 1/2” - Ridge Board
1 - 3/4” x 8 1/2” x 72” - Ridge Board
4 - 1/2” x 4 1/2” x 68 1/4” - Soffits
3 - 3/4” x 3 1/2” x 72”- Gussets (angle cut on both ends)
D. Plywood Roof Section
2 - 5/8” x 48” x 81 1/2” - Roof Plywood-Outside Long
2 - 5/8” x 48” x 38 3/4” - Roof Plywood- Outside Short
1 - 5/8” x 45 1/2” x 81 1/2” - Roof Plywood-Center Long
1 - 5/8” x 45 1/2” x 38 3/4” - Roof Plywood- Center Short
2 - 3/4” x 1 1/2” x 36 1/2” & 4 - 3/4”x 1 1/2”x 40 - Facia Nailing Strips
12 - 3/4” x 3/4” x 48” - Polygal Support Cleats
3 - 1/2” x 2 1/2” x 44” - Mid Ridge Caps for Polygal
2 - 1/2” x 5 1/2” x 44” - Outside Ridge Caps for Polygal - Facia cleats
attached
2 - 1/2” x 3 1/2” x 44” - Center Ridge Caps for Polygal
6 - 20 1/4” x 48” - Polygal Panels
E. Miscellaneous Section
Bottom Skirting
12 - 1/2” x 4 1/2” x 45 1/4” - Bottom Skirting - Bevel
6 - 1/2” x 1 1/2” x 45 1/4” - Top Wall Trims - Bevel
Corner & Wall Trim
4 - 3/4” x 2 1/2” x 75” - Filler Trim
4 - 1/2” x 4 1/2” x 82” - Vertical Corner Trim
5 - 1/2” x 2 1/2” x 87” - Vertical Trim
8 - 1/2” x 2 1/2” x 79” - Vertical Trim
2 - 1/2”x 4 1/2” x 58 1/2” - Horizontal Gable Trim (Left) -angled
2 - 1/2”x 4 1/2” x 58 1/2” - Horizontal Gable Trim (Right) -angled
1 - 1/2” x 2 1/2” x 32” - Horizontal Door Trim (above Door)
1 - 1/2” x 2 1/2” x 8” - Horizontal Narrow Wall Trim (above Wall)
Facia Trim
2 - 3/4” x 3 1/2” x 82 1/8” - Angle Cut Front/Rear Facia Trim (L)
2 - 3/4” x 3 1/2” x 82 1/8” - Angle Cut Front/Rear Facia Trim (R)
4 - 3/4” x 3 1/2” x 71 1/2” - Side Facia
4 - Facia Detail Plates -Sides - (2@3 1/2 & 2@4 1/2” High)
2 - Pentagon Detail Plates (front and back)
4 - Triangular Corner Gable Trim Pieces (2 L / 2R) Found in Gable -
see step 50
Flower Boxes & Window Trim
7 - Flower Box Kits
4 Reg Window Trim Pkgs: 1 x 24 1/16” Top, 3 x 23” Bottom & Sides
6 Narrow Window Trim Pkgs: 1 x 19 7/8” Top, 2 x 21 7/16” Sides,
1 x 18 3/4” Bottom
Potting Shelves
3 - 16” x 45” - Long Potting Shelves
1 - 16” x 41” - Short Potting Shelf
4 - 1 1/2” x 2 1/2” x 38” - Potting Shelf Legs
**Miscellaneous Pieces
1 pc - Spare Wall Siding
2 pcs - Spare Shingles - use to shim door, etc
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
