Thank you for purchasing our 8x8 Sunshed Garden Shed.
Please take the time to identify all the parts prior to assembly.
Parts Lists: 8x8 Sunshed
A. Floor Section
2 - 45 1/2” x 75” - Floor Joist Frames (Interior Joist Unattached)
2 - 45 1/2” x 21” - Floor Joist Frames (Interior Joists Attached)
4 - 1 1/2” x 3 1/2” x 71 3/4" - Floor Joists
2 - 45 3/8” x 74 7/8” - Floor Plywood
2 - 45 3/8” x 20 7/8” - Floor Plywood
5 - 1 1/2” x 3 1/2” x 60” - Floor Runners - Long
5 - 1 1/2” x 3 1/2” x 31” - Floor Runners - Short
B. Wall Section
Main Wall Panels
3 - 45 1/2” x 84” - Solid Wall Panels
3 - 1 1/2" x 2 1/2" x 45 1/2" Wall Plates
2 - 45 1/2” x 84” - Window Wall Panels
2 - 45 1/2” x 75” - Double Window Walls
1 - 12” x 73” - Narrow Wall Panel
1 - 31 1/2” x 72” Dutch Door - 2pcs (42” and 30” high)
1 - 45 1/2” x 9” - Wall Extendor
2 - 3/4” x 3 1/2” x 60” - Horizontal Wall Extendor Brace (front/back)
2 - 3/4” x 3 1/2” x 30” - Horizontal Wall Extendor Brace (front/back)
2 - 3/4” x 3 1/2” x 65 3/4” - Horizontal Wall Extendor Brace (side)
2 - 3/4” x 3 1/2” x 20 1/4” - Horizontal Wall Extendor Brace (side)
Door Jamb, Header & Door Stops
1 - 1 1/2” x 3 1/8” x 73” - Vertical Door Jamb
1 - 2” x 3 1/8” x 45 1/2” - Door Header
2 - 1/2” x 2 1/2” x 72” - Interior Vertical Door Stops
Gable Walls
2 - Front and Rear Gable Walls - Triangular shaped
(33 3/4 degrees on 1 side / 22 1/2 degrees on other)
2 - Triangular Gable Trims - (L/R) Found stapled to inside of Gable in
each corner - see step 63)
Top Wall Plates
1 - 3/4” x 2 1/2” x 86” - Double Window Wall Side - 22 deg. cut on edge
1 - 1 1/2” x 2 1/2” x 86” - Solid Wall Side - 33.75 deg. cut on edge
2 - 3/4” x 2 1/2” x 73 3/4” Front & Rear
(33 3/4 degrees on 1 end / 22 1/2 degrees on other)
C. Rafter Section
6 - 1 1/2” x 3 1/2” x 77 3/4” - Long Roof Side Rafters (22 1/2 degrees)
6 - 1 1/2” x 3 1/2” x 37 3/4” - Short Roof Side Rafters (33 3/4 degrees)
1 - 3/4” x 4 5/8” x 33 1/2” - Ridge Boards (long roof side)
1 - 3/4” x 4 5/8” x 57 1/2” - Ridge Boards (long roof side)
1 - 3/4” x 5 1/8” x 33 1/2” - Ridge Boards (short roof side)
1 - 3/4” x 5 1/8” x 57 1/2” - Ridge Boards (short roof side)
3 - 3/4” x 3 1/2” x 72 - Gussets (angle cut on both ends)
Soffits
2 - 1/2” x 3 1/2” x 45 1/2” Short Roof Side
2 - 1/2” x 4 1/2” x 45 1/2” Long Roof Side
D. Roof Section
4 - 3/4” x 1 1/2” x 34” - F&R Roof/Facia Nailing Strips
4 - 5/8” x 48” x 37 1/2” - Plywood Roof Panels
8 - 3/4” x 3/4” x 44 1/2” - Polygal Support Cleats
2 - 1/2” x 2 1/2” x 41 1/2” - Mid Ridge Caps for Polygal
1 - 1/2” x 3 1/2” x 41 1/2” - Center Ridge Cap for Polygal
2 - 1/2” x 5 1/2” x 41 1/2” - Outside Caps for Polygal (w nailing strip)
4 - 20 1/4”w x 44” - Polygal Panels
E. Miscellaneous Section
Bottom Skirting
8 - 1/2” x 4 1/2” x 45 1/4” - Bottom Skirting
Corner & Wall Trim
2 - 5/8” x 2 1/2” x 75” - Filler Trim Short Wall Side
2 - 5/8” x 2 1/2” x 84” - Filler Trim Tall Wall Side
2 - 1/2” x 4 1/2” x 82” - Corner Trim Short Wall Side
2 - 1/2” x 4 1/2” x 87” - Corner Trim Tall Wall Side
3 - 1/2” x 2 1/2” x 87” - Front Door Trim & Rear Wall Seam Trim
3 - 1/2” x 2 1/2” x 88” - Tall Wall Vertical Trim
3 - 1/2” x 2 1/2” x 79” - Short Wall Vertical Trim
1 - 1/2” x 2 1/2” x 32” - Horizontal Door Trim (above Door)
1 - 1/2” x 2 1/2” x 8 3/4” - Horizontal Narrow Wall Trim (above Wall)
2 -1/2” x 4 1/2 x 85 1/2” - Hor.Gable Trim (F & R) Angle cut 1 end
Facia Trim
2 - 3/4” x 3 1/2” x 79 1/4” - Angle Cut Front/Rear Facia Trim
2 - 3/4” x 3 1/2” x 38 3/4” - Angle Cut Front/Rear Facia Trim
4 - 3/4” x 3 1/2” x 47 7/8” - Side Facia
2 - Facia Detail Plates (sides)
2 - Pentagon Detail Plates (front and back)
Flower Boxes
4 - Flower Box Kits
Potting Shelves
2 - Long Potting Shelves
1 - Short Potting Shelf
3 - 1 1/2” x 2 1/2” x 38” - Potting Shelf Legs
Window Inserts/Trim
2 Reg. Window Inserts
4 Small Window Inserts
2 Reg. Window Trim Pkg: 1 x 24 1/16” top, 3 x 23” bottom & sides
4 Sm. Window Trim Pkg: 1 x 19 7/8” top, 2 x 21 7/16” sides,
1 x 18 3/4” bottom
**Miscellaneous Pieces
1 pc - Spare Wall Siding
2 pcs - Spare Shingles - use to shim door, etc.
Note: All Trim, Facia and Bottom Skirting pieces will be positioned rough face out when installed.
