22
Weight (with battery pack)
7.9 oz (224 g)
Frequency Stability vs. temperature
<2.5ppm
Estimated Battery life
(TX-RX-STBY duty cycle)
Power
10-10-80
duty cycle
5-5-90
duty cycle
1 Watt 8hrs. 16hrs.
4 Watt 5hrs. 9hrs.
FCC Designator
K7GP1808
RECEIVER SPECIFICATIONS*
Sensitivity (12 dB SINAD) ≤0.28uV
Adjacent Channel Selectivity 65dB/60dB (W/N Bandwidth)
Intermodulation 60dB
Spurious Rejection 70dB
Image Rejection 70dB
Audio Output Power 500mW
Audio Distortion ≤5% @ Rated output
Power Supply 100-240V 50/60 Hz 0.2A
Dimensions (without antenna) 1.5 x 2.4 x 4.5 inches (38 x 62 x 114 mm)
TRANSMITTER SPECIFICATIONS*
Modulation Designator
25 kHz
12.5 kHz
11K6F3E
6K12F3E
To Next Page
