Olympus E-M5 Mark II User Manual

108 EN
Menu functions (Custom menus)
4
Option Description
g
Time Code
Settings
Set the time codes to record when shooting a movie.
[Time Code Mode]: Set [DF] (drop frame) to record time
codes corrected for errors with respect to recording time
and [NDF] (no drop frame) to record uncorrected time
codes.
[Count Up]: Set to [RR] (Rec run) to use time codes that
only run during recording and [FR] (Free run) to use time
codes that also run when recording has stopped, including
when the camera is powered off.
[Starting Time]: Set a starting time for the time code. Set
[Current Time] to set the time code for the current frame to
00. To set to 00:00:00:00, select [Reset]. You can also set
time codes using [Manual Input].
Time code is not recorded when the record mode for the
movie is Motion JPEG (H or I).
—
n Info Settings
You can select the content of the information displayed on
the movie recording screen. To hide an item, select the item
and press Q to clear the checkmark.
—
Movie
Specifi cation
Settings
You can set combinations of movie image size and
compression format/bit rate in SET1 to SET4. After
performing these settings, you can select them in movie
image quality mode (P. 62).
[Image Size]: Select between [FHD] (Full HD) and [HD].
[Compression/Bit Rate]: Select from [A-I](All-Intra)/[SF]
(Super Fine)/[F](Fine)/[N](Normal).
—
Movie Effect
Choose [On] to enable movie effects in n mode.
40
Movie+Photo
Mode
Choose the way in which photographs are taken during
movie recording.
[mode1]: Take photographs during movie recording without
stopping recording.
[mode2]: Stop recording to take photographs. Recording will
resume after the photograph is taken.
In mode2 and certain shooting modes, it is only possible to
capture a single-frame as a picture during recording. Other
shooting functions may also be limited.
If the record mode for the movie is Motion JPEG (H or
I), the camera is set to mode2.
41
nShutter
Function
In movie mode, the following shutter button options are
available.
[mode1]: Use the shutter button to shoot still images.
[mode2]: Press the shutter button all the way down to start
and stop movie recording. In mode2, you cannot control
recording using the R button.
—
Z Movie
MENU
c
Z

Olympus E-M5 Mark II Specifications

General

Megapixel	16.1 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	17.2 MP
Image sensor size	4/3 \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Image stabilizer location	Body
Still image resolution(s)	4608x3456, 3200x2400, 1280x960
Lens type	Standard
Filter size	62 mm
Optical zoom	- x
Focal length range	12 - 40 mm
Lens mount interface	Micro Four Thirds (MFT)
Minimum aperture number	-
Number of diaphragm blades	7
Lens structure (elements/groups)	14/9
Maximum focal length (35mm film equiv)	80 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	800
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 1600, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Light exposure control	Program AE
Light exposure correction	±5EV (1/2; 1/3 EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.000125 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Built-in flash	No
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVI, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1280x960@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 640x480@30fps
Memory slots	1
Internal memory	- MB
Compatible memory cards	SDHC, SDXC
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1037000 pixels
Magnification	2 x
Viewfinder type	Electronic
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Scene modes	Beach, Candlelight, Children, Documents, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Resizing, Rotating, Trimming
Photo effects	Black&White, Muted, Sepia, Vivid
White balance	Auto, Custom modes
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 3, 5, 10, 12, 20, 30 s
Camera file system	DCF, DPOF, Exif, PRINT Image Matching III, RAW
Compatible products	FL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R
Image quality adjustment	Saturation
On Screen Display (OSD) languages	BUL, CHI (SIMPL), CHI (TR), CRO, CZE, DEU, ENG, ESP, EST, FIN, FRE, GRE, HUN, IND, ITA, JPN, KOR, LAV, LIT, NOR, RUM, RUS, SER, SLK, SLV, THA, TUR, UKR
Battery type	BLN-1
Product color	Silver
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Cables included	AV, USB
F-number (relative aperture)	2.8

Weight and Dimensions

Depth	44.5 mm
Width	123.7 mm
Height	85 mm
Weight	417 g
Lens length	84 mm
Lens weight	382 g
Lens diameter	69.9 mm
Weight (including battery)	469 g
