Е-41
2)
Adjustment
of
CA8946
(String)
(dislocation
and
entanglement)
8946
is
to
be
threaded
as
follows:
(Remarks:)
o
The
string
should
not
be
dislocated
from
the
pulley.
o
The
width
at
A
and
B
should
be
approximately
the
same.
o
When
8879
is
turned
until
it
hits
the
Cam
Roller,
there
should
be
a
space
of
less
1
mm
between
pulleys
of
the
B
spring
and
the
B spring
plate.
3)
Improper
selection
of
CA8933
(Roller)
(diameter)
8933
comes
in
6
types
(see
next
page).
Referring
to
the
checkup
column
on
the
right,
make
a
proper
selection
and
check
the
operation.
