Olympus Stylus 780 - Camera Diagram and Controls; Camera Body Overview; Buttons and Controls Identification

EN 73
Appendix
CAMERA DIAGRAM
Camera
Flash (P. 15)
Shutter Button
(P. 8, 10)
Self-Timer Lamp
(P. 15, 54)
Lens
(P. 10, 60)
Zoom Button (P. 13)
f/S Button
(Shadow Adjustment
Technology/Erase)
(P. 9, 16)
Arrow Pad (1243)
(P. 12)
e Button (P. 13)
Strap Eyelet
(P. 3)
Battery/Card Compartment
Cover
(P. 4, 62)
Tripod Socket
Connector Cover
(P. 35, 36, 45)
Multi-Connector
(P. 35, 36, 45)
Monitor (P. 33, 74)
m Button
(P. 13)
Microphone (P. 24)
Speaker
o Button
(P. 5, 10)
Card Access Lamp
(P. 47, 54, 63)
h button
(Image stabilizer)
(P. 15)
Mode Dial
(P. 5, 9, 11)
q/< button
(Playback/Print) (P. 16)
g/E Button (P. 17)
