Omnifilter OMNI OM40KCS User Manual

OM32KCS Recharge Cycles:
Table 1 Length of Cycle
Cycle Cycle Description HE Setting Sd Setting HC Setting
1Refi ll 3.5 min 10.5 min 16 min
2 Brine Prep 120 min 120 min 120 min
3 Backwash 1 8 min 8 min 8 min
4* Brine Draw 6 min 19 min 30 min
5* Slow Rinse 35 min 35 min 35 min
6 Re-Pressurize 3 min 3 min 3 min
7 Fast Rinse 1 3 min 3 min 3 min
8 Backwash 2 1 min 1 min 1 min
9 Fast Rinse 2 1 min 1 min 1 min
Table 2 Time remaining to end of cycle
Cycle Cycle Description HE Setting Sd Setting HC Setting
1Refi ll 182 min 202 min 219 min
2 Brine Prep 179 min 192 min 203 min
3 Backwash 1 59 min 72 min 83 min
4* Brine Draw 51 min 64 min 75 min
5* Slow Rinse 45 min 45 min 45 min
6 Re-Pressurize 10 min 10 min 10 min
7 Fast Rinse 1 7 min 7 min 7 min
8 Backwash 2 4 min 4 min 4 min
9 Fast Rinse 2 3 min 3 min 3 min
*The camshaft does not move between cycles 4 and 5. Cycle 5 begins
when the brine in the salt tank runs out and the check valve closes.
OM36KCS Recharge Cycles:
Table 1 Length of Cycle
Cycle Cycle Description HE Setting Sd Setting HC Setting
1Refi ll 3.6 min 11 min 17.48 min
2 Brine Prep 120 min 120 min 120 min
3 Backwash 1 8 min 8 min 8 min
4* Brine Draw 7 min 18 min 23 min
5* Slow Rinse 36 min 36 min 36 min
6 Re-Pressurize 3 min 3 min 3 min
7 Fast Rinse 1 3 min 3 min 3 min
8 Backwash 2 1 min 1 min 1 min
9 Fast Rinse 2 1 min 1 min 1 min
Table 2 Time remaining to end of cycle
Cycle Cycle Description HE Setting Sd Setting HC Setting
1Refi ll 183 min 203 min 214 min
2 Brine Prep 181 min 192 min 197 min
3 Backwash 1 61 min 72 min 77 min
4* Brine Draw 53 min 64 min 69 min
5* Slow Rinse 46 min 46 min 46 min
6 Re-Pressurize 10 min 10 min 10 min
7 Fast Rinse 1 7 min 7 min 7 min
8 Backwash 2 4 min 4 min 4 min
9 Fast Rinse 2 3 min 3 min 3 min
*The camshaft does not move between cycles 4 and 5. Cycle 5 begins
when the brine in the salt tank runs out and the check valve closes.
OM40KCS Recharge Cycles:
Table 1 Length of Cycle
Cycle Cycle Description HE Setting Sd Setting HC Setting
1Refi ll 4.1 min 13.0 min 20.1 min
2 Brine Prep 120 min 120 min 120 min
3 Backwash 1 8 min 8 min 8 min
4* Brine Draw 8 min 24 min 36 min
5* Slow Rinse 43 min 43 min 43 min
6 Re-Pressurize 3 min 3 min 3 min
7 Fast Rinse 1 3 min 3 min 3 min
8 Backwash 2 1 min 1 min 1 min
9 Fast Rinse 2 1 min 1 min 1 min
Table 2 Time remaining to end of cycle
Cycle Cycle Description HE Setting Sd Setting HC Setting
1Refi ll 193.1 min 205.0 min 237.1 min
2 Brine Prep 189 min 192 min 217 min
3 Backwash 1 69 min 72 min 97 min
4* Brine Draw 61 min 64 min 89 min
5* Slow Rinse 53 min 53 min 53 min
6 Re-Pressurize 10 min 10 min 10 min
7 Fast Rinse 1 7 min 7 min 7 min
8 Backwash 2 4 min 4 min 4 min
9 Fast Rinse 2 3 min 3 min 3 min
*The camshaft does not move between cycles 4 and 5. Cycle 5 begins
when the brine in the salt tank runs out and the check valve closes.
Recharge Cycle Requirements:
OM26KCS
HE Sd HC
Salt/Recharge
(lbs)
2.7 8.5 13.2
Regeneration
Time (Min)
62 82.5 96
Water to Drain
(gal)
37.5 43.2 46.6
Max. Flow to
Drain (gpm)
2.1 2.1 2.1
OM32KCS
HE Sd HC
Salt/Recharge
(lbs)
3.3 10.4 16
Regeneration
Time (Min)
60.5 80.5 97
Water to Drain
(gal)
47.4 51.8 57.1
Max. Flow to
Drain (gpm)
2.7 2.7 2.7
OM36KCS
HE Sd HC
Salt/Recharge
(lbs)
3.6 11.3 17.5
Regeneration
Time (Min)
63 85.5 100.5
Water to Drain
(gal)
48.2 55.4 59.7
Max. Flow to
Drain (gpm)
2.7 2.7 2.7
RECHARGE continued
12 • JA13 OM26KCS, OM32KCS, OM36KCS, OM40KCS
