A Air outlet
B Control panel
C Wheels
D Wooden cabinet
E Remote control
Ref Description
F Air intake
G Temp sensor
H Power switch
I Cord clamp
Ref Description
A
B
D E
F
G
H
C
I
ON/OFF
TEMP.
UP
TEMP.
DOWN
TIMER °C/°F
MODE
IMPORTANT SAFETY INSTRUCTIONS
SPECIFICATIONS
IN THE BOX
When using this electric unit, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and
injury to persons, including the following:
1. Read ALL instructions before using this unit.
2. CAUTION: Risk of Electric Shock. DO NOT open or try to
repair the heater yourself.
3. This heater may get hot when in use. To avoid burns, DO
NOT let bare skin touch hot surfaces. If provided, use
handles when moving this heater.
4. Keep combustible materials, such as furniture, pillows,
bedding, paper, clothes, and curtains at least 3 ft from the
front of the heater and keep them away from the sides,
top, and rear. DO NOT place towels or other objects on the
heater.
5. Extreme caution is necessary when any heater is used by or
near children or the disabled, or when the heater is left
operating and unattended.
6. DO NOT operate any heater with a damaged cord or after
the heater malfunctions, has been dropped or damaged in
any manner. Return heater to authorized service facility for
examination, electrical or mechanical adjustment, or repair.
7. This heater is not intended for use in bathrooms, laundry
areas and similar indoor locations. NEVER locate heater
where it may fall into a bathtub or other water container.
To protect against electrical hazards, DO NOT immerse in
water or other liquids.
8. DO NOT touch the control panel or plug with a wet hand.
9. DO NOT run cord under carpeting. DO NOT cover cord with
throw rugs, runners, or similar coverings. Arrange cord
away from traffic area and where it will not be tripped
over.
10. DO NOT insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause an electric
shock or fire, or damage the heater.
11. To prevent a possible fire, DO NOT block the air intakes or
exhaust in any manner. DO NOT use on soft surfaces, like a
bed, where openings may become blocked.
12. A heater has hot and arcing or sparking parts inside. DO
NOT use in areas where gasoline, paint, explosive and/or
flammable liquids are used or stored. Keep unit away from
heated surfaces and open flames.
13. Always plug heaters directly into a wall outlet/receptacle.
Never use with an extension cord or relocatable power tap
(outlet/power strip).
14. To avoid fire or shock hazard, plug the unit directly into a
120 V AC electrical outlet.
15. To disconnect heater, turn controls to OFF, then remove
plug from outlet. Pull firmly on the plug, DO NOT unplug by
pulling on the cord.
16. Always unplug the unit before moving or cleaning, or
whenever the heater is not in use.
17. Use only for intended household use as described in this
manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to
persons. The use of attachments not recommended or sold
by unauthorized dealers may cause hazards.
18. Always use on a dry, level surface. Use on floor only.
19. DO NOT use outdoors.
20. WARNING: To reduce the risk of fire or electric shock, DO
NOT use this unit with any solid-state speed control device.
21. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void your
warranty. The inside of the unit contains no user
serviceable parts. Qualified personnel should perform all
servicing only.
22. Connect to properly grounded outlets only.
PRODUCT DIAGRAM
SAFETY FEATURES
WARNING: This heater has a voltage rating of
120 volts. The cord has a plug as shown in A. An adapter
as shown in C is available for connecting three-blade
grounding-type plugs to two-slot receptacles. The
grounding lug extending from the adapter must be
connected to a permanent ground such as a properly
grounded outlet box. The adapter should not be used if
a three-slot grounded receptacle is available.
DO NOT DEFEAT THE SAFETY PURPOSE OF THE
GROUNDED PLUG.
WARNING: It is normal for the power cord to feel warm
to the touch; however, a loose fit between the outlet
and the plug may cause overheating of the plug. If this
occurs, try inserting the plug into a different outlet.
Contact a qualified electrician to inspect the original
outlet for damage.
Tip-Over Safety Feature
This heater is equipped with a tip-over safety feature. Once the
heater is tipped over, an internal switch will automatically shut
the heater off. Once the heater is restored an upright position,
the heater will reset. To continue operation, turn on the heater
using the supplied remote control or the control panel on the
heater.
SAVE THESE INSTRUCTIONS
Voltage Rating 120 V (60 Hz)
Power Consumption 1500 W
Unit Size 13.1 in. (W) x 16.7 in. (D) x 17.7 in. (H)
Unit Weight 24.9 lbs
• INFRARED ZONE HEATING SYSTEM
• REMOTE CONTROL (2 AAA batteries not Included)
• INSTRUCTION BOOKLET
Overheat Safety Feature
This heater is equipped with a overheat safety feature. When the
heaters internal components reach a certain temperature that
could cause overheat and possible fire, the heater will
automatically shut off.
METAL SCREW
COVER OF GROUNDED
OUTLET BOX
(A)
(B)
(C)
(D)
GROUNDING PIN
GROUNDING MEANS
ADAPTER
GROUNDING PIN
