25 Power on/off
26 Power input with fuse holder. Used to plug in the supplied power cable. Only replace
the fuse when the device is disconnected from mains. Only use fuses of the same
rating and power. The correct fuse value is specified on the rear panel.
27 Ground clamping screw for turntables
28 Gain control for matching the input amplification of phono input 2 to line level sources
29 Switches the PH 2/LINE 3 jacks for channel 2 between phono and line input
30 Stereo inputs (RCA) for channel 2 for connecting units with line level outputs such as
CD players (LINE 3, 4) or turntables with magnetic system (PH 2)
31 Balanced XLR output L/R for connecting amplifiers or other units with line level input
32 Stereo output (RCA) for connecting amplifiers or other units with line level input
33 Balanced XLR output L/R for connecting a further amplifier, e.g. for the monitoring
system or PA application in a secondary room
34 Stereo output (RCA) for connecting a further amplifier, e.g. for the monitoring system
or PA application in a secondary room
35 Stereo output (RCA) for connecting a recording unit
36 Ground clamping screw for turntables
37 Switches the PH 1/LINE 1 jacks for channel 1 between phono and line input
38 Gain control for matching the input amplification of phono input 1 to line level sources
39 Stereo inputs (RCA) for channel 1 for connecting units with line level outputs such as
CD players (LINE 1, 2) or turntables with magnetic system (PH1)
