OMPHOBBY EDGE 540 - Recommended Control Surface Settings

RecommendedSettingsofDualRatesand
ExponentialsofControlSurfaces
ZhuhaiEdgeSmartDriveTechnologyCo.,Ltd.
www.omphobby.com
Lowrate Lowrateexp Highrate Highrateexp
Aileronservo
10-20° 30-50% 35-40° 60-70%
Elevator 15-25° 30-50% 45-55° 60-70%
Rudder 30-40° 35-55% 40-55° 65-75%
ThepreferredCGforthisplaneisat170mmbackfromtheleading
measuredatthewingtip
