Omron NJ Series Troubleshooting Manual

3 Error Tables
3-164
NJ-series Troubleshooting Manual (W503)
5401545A hex Motion Control Instruction Re-execu-
tion Disabled (MasterOffset)
Instructions W502
5401545B hex Motion Control Instruction Re-execu-
tion Disabled (MasterScaling)
Instructions W502
5401545C hex Motion Control Instruction Re-execu-
tion Disabled (MasterStartDistance)
Instructions W502
5401545D hex Motion Control Instruction Re-execu-
tion Disabled (Continuous)
Instructions W502
5401545E hex Motion Control Instruction Re-execu-
tion Disabled (MoveMode)
Instructions W502
5401545F hex Illegal Auxiliary Axis Specification Instructions W502
54015460 hex Illegal Axis Specification Instructions W502
54015461 hex Illegal Axes Group Specification Instructions W502
54015462 hex Illegal Master Axis Specification Instructions W502
54015463 hex Motion Control Instruction Re-execu-
tion Disabled (SlaveOffset)
Instructions W502
54015464 hex Motion Control Instruction Re-execu-
tion Disabled (SlaveScaling)
Instructions W502
54015465 hex Motion Control Instruction Re-execu-
tion Disabled (StartPosition)
Instructions W502
54015466 hex Instruction Execution Error with
Undefined Home
Instructions W502
54015467 hex Motion Control Instruction Re-execu-
tion Disabled Position Type)
Instructions W502
54015468 hex Unused Axis Specification for Master
Axis
Instructions W502
54015469 hex First Position Setting Out of Range Instructions W502
5401546A hex Last Position Setting Out of Range Instructions W502
5401546B hex Illegal First/Last Position Size Rela-
tionship (Linear Mode)
Instructions W502
5401546C hex Master Sync Start Position Setting
Out of Range
Instructions W502
5401546D hex Slave Sync Start Position Setting Out
of Range
Instructions W502
5401546E hex Duplicate Latch ID for Trigger Input
Condition
Instructions W502
5401546F hex Jerk Override Factor Out of Range Instructions W502
54015470 hex Acceleration/Deceleration Override
Factor Out of Range
Instructions W502
54015471 hex First Position Method Specification
Out of Range
Instructions W502
54015472 hex Motion Control Instruction Re-execu-
tion Disabled (First Position Method)
Instructions W502
54015474 hex Unused Axis Specification for Auxil-
iary Axis
Instructions W502
54015475 hex Position Gear Value Error Instructions W502
54015476 hex Position Gear Master Axis Zero
Velocity
Instructions W502
54015478 hex Target Position Setting Out of Range Instructions W502
54015479 hex Travel Distance Out of Range Instructions W502
5401547A hex Cam Table Start Point Setting Out of
Range
Instructions W502
Event code Event name Functional classification Reference

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
