NX-series Digital I/O Unit User’s Manual (W521)
A-5 List of NX Objects
A
A-5-3 Digital Output Units
These objects accept I/O allocations.
You cannot access the objects that are described below with the Read NX Unit Object instruction or the
Write NX Unit Object instruction.
Refer to the NJ-series Instructions Reference Manual (Cat. No. W502-E1-07 or later) for details on the
Read NX Unit Object instruction or the Write NX Unit Object instruction.
*1. The default value and data range for Number of Entries are as follows.
Objects That Accept I/O Allocations
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
7000  Bit Output  
00 Number of Entries
*1 *1
 USINT RO Not
pos-
sible

01 Output Bit 00 FALSE TRUE or
FALSE
 BOOL RW Pos-
sible
N
02 Output Bit 01 FALSE TRUE or
FALSE
 BOOL RW Pos-
sible
N
03 Output Bit 02 FALSE TRUE or
FALSE
 BOOL RW Pos-
sible
N
04 Output Bit 03 FALSE TRUE or
FALSE
 BOOL RW Pos-
sible
N
NX Units Default value Data range
NX-OD3121/OD3153/OD3256/OD3257 4 4 (fixed)
NX-OD2154/OD2258/OC2633/OC2733 2 2 (fixed)
Other models 0 0 (fixed)
