Appendices
A - 92
NX-series Digital I/O Unit User’s Manual (W521)
*1. The default value and data range for Number of Entries are as follows.
*2. Detailed data for Output Bit 8 bits are as follows.
Bit 0: Output Bit 00
Bit 1: Output Bit 01
·
·
·
Bit 7: Output Bit 07
*1. The default value and data range for Number of Entries are as follows.
*2. Detailed data for Output Bit 16 bits are as follows.
Bit 0: Output Bit 00
Bit 1: Output Bit 01
·
·
·
Bit 15: Output Bit 15
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
7001  BYTE Output  
00 Number of Entries
*1 *1
 USINT RO Not
pos-
sible

01 Output Bit 8 bits 00 hex 00 to FF hex  BYTE RW Pos-
sible
N
NX Units Default value Data range
NX-OD4121/OD4256 1 1 (fixed)
Other models 0 0 (fixed)
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
7002  Word Output  
00 Number of Entries
*1 *1
 USINT RO Not
pos-
sible

01 Output Bit 16 bits 0000 hex 0000 to FFFF
hex
 WORD RW Pos-
sible
N
NX Units Default value Data range
NX-OD5121/OD5121-5/OD5256/OD5256-5 1 1 (fixed)
Other models 0 0 (fixed)
