A - 135
Appendices
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
A-3 Sysmac Error Status Codes
A
A-3-2 Error Description
Event name Overspeed 2 Event code 3840 0000 hex
Description
The motor speed exceeded the value set on Overspeed Detection Level Setting at Immediate Stop
(3615 hex).
Source
EtherCAT Master Function Module
Source
details
Slave
Detection
timing
While power is
supplied to
motor
Error
attributes
Level
Minor fault
Recovery
Error reset
(after resetting slave
errors)
Log category
System
Effects
User program
Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators
EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
–––
System
-defined
variables
Variable Data type Name
None – –
Cause and
correction
Assumed cause Correction Prevention
The velocity command value is too
large.
Reduce the velocity. Adjust the
input frequency, dividing ratio, and
multiplication ratio of the command
pulse.
Set the velocity command value in
a range that does not exceed the
overspeed detection level at
immediate stop. Adjust the input
frequency, dividing ratio, and
multiplication ratio of the
command pulse.
There is overshooting. Adjust the gain. Do not make the gain too large.
The wiring is incorrect. Wire the external encoder
correctly as shown in the wiring
diagram.
Wire the external encoder
correctly as shown in the wiring
diagram.
Attached
information
None
Precautions/
Remarks
“26” is displayed on the Servo Drive front panel and F126 is given as the AlarmCode (4001 hex).
Event name Command Error Event code 3841 0000 hex
Description The position command variation after the electronic gear exceeded the specified value.
Source
EtherCAT Master Function Module
Source
details
Slave Detection
timing
Continuously
Error
attributes
Level
Minor fault
Recovery
Error reset
(after cycling slave
power)
Log category
System
Effects
User program
Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators
EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
–––
System
-defined
variables
Variable Data type Name
None – –
Cause and
correction
Assumed cause Correction Prevention
The change in position command
is too large.
Reduce the electronic gear ratio. Adjust the electronic gear ratio so
that the changes in the position
command are not too large.
The backlash compensation
amount is too large.
Reduce the backlash
compensation amount.
Adjust the backlash
compensation amount so that the
changes in the position command
are not too large.
Attached
information
None
Precautions/
Remarks
“27” is displayed on the Servo Drive front panel and F427 is given as the AlarmCode (4001 hex).
